Effective Diameter: 600 - 4000mm

Effective Length: 800 - 20000mm

Operating Temperature: 300 - 450℃

Operating Pressure: 1.5 - 5.0Mpa

Working Medium: Nitrogen

Application Fields:
Primarily used in the aerospace and military industries. It is configured for the curing process of composite materials based on polyimide resin systems – the highest temperature-resistant resins available for composites to date. Most of these resins require a curing temperature of 320–380℃ (with a rising trend) and a curing pressure of over 1.5 Mpa, even above 4 Mpa. Despite its sophisticated technology, the SINOMAC High-Temperature & High-Pressure Autoclave operates with exceptional stability, fully meeting the demands of this field.

Effective Diameter: ≥ 4500mm

Effective Length: ≥ 8000mm

Operating Temperature: 100–450℃

Operating Pressure: 0.8 – 5.0Mpa

Working Medium: Compressed Air / Nitrogen

Application: Primarily used in strategic sectors such as aerospace and national defense. It is a cutting-edge piece of equipment designed for the integral co-curing/co-bonding processes of large and extra-large composite components. Typical products include new-generation commercial aircraft fuselage barrels, integral wing panels, helicopter main rotors, launch vehicle fairings and cabin sections, as well as large structural components for satellites and space stations.

SINOMAC Extra-Large Autoclave represents a high level in the field of high-end composite manufacturing equipment. With extremely high technology integration and stable, reliable operation, it serves as a core platform supporting the lightweight and integrated manufacturing of high-end equipment.

Effective Diameter: 3500 - 4500mm

Effective Length: 6000 - 20000mm

Operating Temperature: 100 - 450℃

Operating Pressure:: 0.8 - 5.0Mpa

Working Medium: Compressed Air / Nitrogen

Application Fields: A key piece of equipment for manufacturing medium and large composite components, widely used in aerospace, national defense, and high-end industries. Typical products include aircraft wing/empennage panels, helicopter fuselage sections, rudders, fairings, missile bodies, large UAV components, and load-bearing structures for high-speed rail and new energy sectors. With mature technology and stable performance, SINOMAC Large Autoclave is the core guarantee for large-scale, high-quality production of high-performance composite components.

Effective Diameter: 2000 - 3500mm

Effective Length: 3000 - 12000mm

Operating Temperature: 100 - 450℃

Operating Pressure: 0.8 - 5.0Mpa

Working Medium: Compressed Air / Nitrogen

Applications: Ideal for curing medium-sized composite components and multi-material processing. Widely used in aerospace, high-end sports equipment, industrial manufacturing and scientific research. Typical products include aircraft control surfaces, cabin doors, fairings, satellite brackets, large UAV fuselages, F1 parts, high-performance bicycle frames and industrial high-pressure cylinders. SINOMAC Medium-Sized Autoclave balances performance, flexibility and cost-effectiveness excellently, making it one of the most widely used models.
